Momentive TSE326M

Description

Momentive TSE326M

Momentive TSE326M (also known as TSE326) is a one-part, heat-curing silicone adhesive engineered for assembly, sealing, and gasketing applications that demand high thermal resistance and reliable adhesion. It cures quickly when exposed to heat, forming a durable, resilient elastomer that adheres to a wide variety of substrates including aluminum, steel, glass, and most plastics—often without primer.

This non-corrosive silicone offers low shrinkage, outstanding dielectric strength (22 kV/mm), and mechanical flexibility for long-term stability in high-heat environments. It’s widely used in electronics, automotive, and industrial assemblies for bonding and sealing components subject to thermal stress.

Momentive recommends SS4155 silicone primer when stronger chemical adhesion is needed for difficult substrates.

Uses of the Product

• High-temperature bonding and sealing of metal, plastic, and ceramic parts.

• Electrical and electronic assembly adhesive.

• Gasketing and sealing for ovens, compressors, and heaters.

• Automotive engine and sensor sealing applications.

• Industrial assembly bonding in high heat or vibration environments.

Applications

• Electronics & Electrical Manufacturing

• Automotive & Powertrain Components

• Industrial Equipment Assembly

• Aerospace & Defense Hardware

• Heat-Resistant Sealing and Gasketing

Technical Specifications

Uncured Properties:

• Appearance: Reddish brown

• Viscosity: 28 Pa·s (flowable)

• Cure Type: Heat cure (condensation system)

Cured Properties (1 hour @ 150 °C):

• Specific Gravity: 1.45

• Hardness: 43 Shore A

• Tensile Strength: 3.4 MPa

• Elongation: 170 %

• Adhesion Strength (Al lap shear): 2.0 MPa

• Dielectric Strength: 22 kV/mm

• Dielectric Constant (60 Hz): 3.3

• Dissipation Factor (60 Hz): 0.02

• Volume Resistivity: 2 × 10¹⁵ Ω·cm

• Linear Expansion Coefficient: 1.7 × 10⁻⁴ 1/K

Typical Cure Schedule:

• 100 °C – 4 hours

• 125 °C – 2 hours

• 150 °C – 1 hour

Compatibility: Avoid contact with sulfur, amines, or certain rubber compounds which may inhibit curing.

Pack Size: 1 Kg Bottle
Shelf Life: 12 months (unopened, below 30 °C)

Why Buy From Maisam Dubai

• Supplier of genuine Momentive heat-curable silicones.

• Expertise in high-temperature bonding and electronic sealing solutions.

• Technical support for industrial and OEM applications.

• Competitive pricing and fast regional delivery.

• Serving industries across UAE, Saudi Arabia, Oman, Qatar, Bahrain, and Kuwait.

FAQs

Q1. What is Momentive TSE326M used for?
It is used for bonding and sealing components in high-temperature industrial, automotive, and electronic assemblies.

Q2. Does it require a primer?
Usually no, but SS4155 primer can improve adhesion on difficult substrates.

Q3. What is the curing method?
It cures by heat acceleration — typically 1 hour at 150 °C.

Q4. Is it electrically insulating?
Yes, with a dielectric strength of 22 kV/mm and resistivity of 2 × 10¹⁵ Ω·cm.

Q5. What is its maximum operating temperature?
It retains strength and flexibility above 200 °C.

Q6. Do you supply across GCC?
Yes, Maisam Dubai supplies TSE326M across UAE, Saudi Arabia, Oman, Qatar, Bahrain, and Kuwait.
